19 Inch High Quality and Competitive Price Worm Gear W19 Open Slew Drive Single Axis Hydraulic Motor Slewing Drive

$800.00

SAVE Sold out

🔄 19 Inch High Quality and Competitive Price Worm Gear W19 Open Slew Drive - Single Axis Hydraulic Motor Slewing Drive

Professional 19-inch high quality worm gear W19 open slew drive with single axis hydraulic motor integration, offered at competitive prices without compromising quality. Our advanced worm gear technology delivers superior rotational performance with exceptional load capacity for ultra heavy-duty rotating machinery requiring maximum torque and cost-effective industrial solutions.

✨ Key Features

19-Inch Ultra Heavy-Duty Design: Maximum capacity for the most demanding industrial applications
High Quality Worm Gear Technology: Premium worm gear for superior performance
Competitive Price Advantage: Exceptional value without quality compromise
W19 Open Type Design: Easy maintenance and installation access
Single Axis Configuration: Simplified control and reliable operation
Hydraulic Motor Integration: Seamless hydraulic motor compatibility
Premium Materials: 42CrMo, 50Mn steel construction
ISO Certified Quality: ISO9001 & ISO4001 certified manufacturing
1-Year Warranty: Comprehensive guarantee coverage

📏 Technical Performance Specifications

Performance Parameter	Specification
Model	W19 Open Slew Drive
Size	19 Inch Diameter
Output Speed	2.5 rpm
Rated Output Torque	18.5 KN.m
Overturning Moment	196 KN.m
Holding Torque	80 KN.m
Axial Load	1800 KN
Radial Load	675 KN
Gear Ratio	120:1
Material	42CrMo, 50Mn, Customizable

⚙️ High Quality Worm Gear Technology

The W19 features premium worm gear technology with 120:1 gear ratio, providing exceptional torque multiplication and superior load handling. The high quality worm gear design ensures reliable performance in the most demanding industrial applications with maximum efficiency and durability.

🏗️ Ultra Heavy-Duty Industrial Applications

Specifically engineered for ultra heavy-duty industrial machinery including large-scale cranes, mining equipment, port machinery, steel mills, and specialized industrial rotating platforms. The 19-inch design provides maximum load capacity for the most demanding industrial environments.

🛡️ Quality Assurance & Certification

Each W19 open slew drive undergoes comprehensive testing including:

ISO9001 & ISO4001 quality management certification
Ultra heavy-duty load capacity verification
Maximum torque performance testing
Worm gear efficiency validation
Hydraulic motor compatibility testing
Industrial application durability testing

🔧 Installation & Maintenance Advantages

Open type design for easy access
Single axis simplicity
Ultra heavy-duty construction
Professional installation guidance
Industrial-grade maintenance design
Technical support available

🌍 Ultra Heavy-Duty Industrial Applications

Perfect for ultra heavy-duty industrial machinery, large-scale mining equipment, port cranes, steel mill equipment, heavy material handlers, and specialized industrial rotating systems requiring maximum torque capacity and reliability.

💰 Competitive Price Advantages

Origin: Anhui, China - Cost-effective manufacturing
Competitive Pricing: High quality at competitive prices
Value Engineering: Maximum performance per dollar invested
Customization: Available for specific industrial requirements
Packaging: Professional plywood case protection
Certificates: ISO9001 & ISO4001 certified
Warranty: 1-year comprehensive coverage

📞 Technical Support & Custom Solutions

Contact our engineering team for custom specifications, technical consultations, and bulk order pricing. We provide comprehensive support from selection to installation and ongoing maintenance for ultra heavy-duty industrial applications at competitive prices.

cheap and good quality, just shipping time varies depending on different destination countries

client anonymous
very nice

client anonymous
i love the product, much cheaper than dealers in italy

client anonymous

check_box

This Gear Is Fully Cutomizable

1- send us your gear parts graph or tell us your specific model / many customization progress are free of charge

2- online live chat with us to know more about customization of this item

View full details
